Airmar - 220WX/200WX NMEA 0183 / 2000® WeatherStation® - Relative Humidity - RS232

Original price $1,738.00 - Original price $1,738.00
Original price
$1,738.00
$1,738.00 - $1,738.00
Current price $1,738.00

FREE Domestic Shipping Orders $49+

Easy 30-Day Returns

Best Price Guarantee

Expert Customer Service

Airmar - 220WX NMEA 0183 / 2000® WeatherStation® - Relative Humidity - RS232

The 220WX NMEA 0183 / 2000® WeatherStation® with Relative Humidity module and RS232 interface, specifically designed to meet the demanding needs of commercial fishing weather monitoring applications. In this comprehensive overview, we'll delve into the product description, key highlights, specifications, user perspective, pros and cons, frequently asked questions, and a final verdict.

The Airmar 220WX WeatherStation® is the pinnacle of weather monitoring technology, tailor-made for commercial fishing applications. With a rugged and durable construction, compact footprint, and IPX6 water resistance rating, the 220WX thrives in the harsh marine environment. Utilizing advanced sensors, including ultrasonic measurement of wind speed and direction, barometric pressure, temperature, GPS position, and three-axis compass, it accurately calculates theoretical wind data based on vessel speed and heading. The addition of the Relative Humidity module enables dew-point and heat-index calculations, further enhancing its utility.


Key Highlights

  • Ultrasonic measurement of apparent and theoretical wind speed and direction.
  • Comprehensive sensor suite including barometric pressure, temperature, GPS position, and three-axis compass.
  • Addition of Relative Humidity module for advanced weather data analysis.


Specifications

  • Brand: Airmar Technology
  • Air Temp Accuracy: ±1.1°C at 20°C
  • Air Temp Range: -40 to 80°C (-40 to 176°F)
  • Barometric Pressure Accuracy: ±0.5 hPa at 25°C (or better)
  • Barometric Pressure Range: 300 to 1100 hPa
  • Certs And Standards: CE, IPX6 (IPX4 with optional Relative Humidity sensor), RoHS, IEC standards
  • Comm Method: NMEA 2000®
  • Communications Available Hardware Interface: Serial RS-232, Serial RS-422, CAN
  • Communications Available Protocol: Comma delimited ASCII, NMEA 0183, NMEA 2000
  • Communications Serial Output Rate: 1 Hz typical. User selectable. 10 Hz maximum recommended
  • Country of Origin: USA
  • Display Connector: Cable Required
  • Exterior Color: White
  • GPS Position Accuracy: 3 m (10') CEP
  • Mounting Thread: Standard 1”-14 UNS (3/4” NPT optional)
  • NMEA 2000 LEN: 2
  • Operating Temp Range: -25 to 55°C (-13 to 131°F)
  • Optional RH Accuracy: ±5% RH at 0 to 90% RH at 20°C
  • Optional RH Range: 0 to 100% RH
  • Optional RH Resolution: 0.1% RH
  • Pitch Roll Accuracy: ±1° in range of ±30°
  • Power Supply Voltage: 9 to 40 VDC
  • Waterproof Rating: IPX6 (Relative Humidity/IPX4)
  • Weight: 300 g (0.7 lb.)
  • Wind Direction Accuracy: ±3° at 10 m/s
  • Wind Speed Accuracy: 5% at 10 m/s (19 knots) at 4 angles


User Perspective

From a commercial fisherman's perspective, the Airmar 220WX WeatherStation® is an indispensable tool for ensuring the safety and efficiency of every voyage. Its rugged construction and comprehensive sensor suite provide accurate and reliable weather data, empowering fishermen to make informed decisions at sea. With the addition of the Relative Humidity module, it offers advanced weather data analysis capabilities, further enhancing its utility and value.


Pros

  • Accurate and reliable weather data
  • Rugged and durable construction
  • Comprehensive sensor suite
  • Addition of Relative Humidity module for advanced weather data analysis
  • Easy to install and use


Cons

  • Additional accessories may be required for full functionality
  • Requires periodic maintenance and calibration


Frequently Asked Questions:

Is the Airmar 220WX WeatherStation® suitable for use in extreme weather conditions?

Yes, the 220WX is designed to withstand harsh marine environments and is IPX6 rated for water resistance.


Can the 220WX WeatherStation® be integrated with existing onboard systems?

Yes, the 220WX supports various communication protocols and hardware interfaces for seamless integration.


Does the 220WX WeatherStation® require regular calibration?

Yes, periodic calibration is recommended to ensure accurate performance.


What is the power supply requirement for the 220WX WeatherStation®?

The 220WX operates on a voltage range of 9 to 40 VDC.


Is the Airmar 220WX WeatherStation® compatible with all types of vessels?

Yes, the 220WX is suitable for use on both marine and land-based vessels.

The Airmar 220WX NMEA 0183 / 2000® WeatherStation® with Relative Humidity module and RS232 interface is the ultimate solution for commercial fishing weather monitoring applications. With its robust construction, comprehensive sensor suite, and advanced weather data analysis capabilities, it provides commercial fishermen with the accurate and reliable weather data they need to ensure safe and efficient operations at sea. While it may require a significant initial investment and periodic maintenance, the benefits it offers far outweigh the costs, making it a valuable asset for any commercial fishing vessel.
